| GENERAL |
| Model |
LM9600 |
| Screen Type |
LED TV |
| Display Size |
55 inches |
| Screen Resolution |
1920 x 1080 |
| Video Processing Engine |
Triple XD Engine |
| Internet Connectivity |
LAN |
| USB Play |
Yes |
| In the Box |
6 Pairs of 3D Glasses Included, Magic Remote (4 mode w/Voice Recognition) |
|
| VIDEO FEATURES |
| Aspect Ratio |
6 Modes (16:9/Just Scan/Set by Program/4:3/ Cinema Zoom 1/Zoom) |
| Dynamic Ratio |
10,000,000:1 |
| View Angle |
N.A |
| Backlight Module |
N.A |
| Brightness |
N.A |
| Panel Type |
N.A |
| Additional Video Features |
LG Smart TV, 3D Ready, TruMotion (Frame Rate): 480 Hz, MPRT: 480 Hz, BLU Type: NANO Full LED, TruMotion 480Hz Response Time, Local Dimming, Analog, Digital: ATSC/NTSC/Clear QAM (1 Tuner), Resolution Upscaler Plus, Picture Mode: 7 Modes (Intelligent Sensor/Vivid/Standard/Cinema/Game/ISF Expert 1/ISF Expert 2), Picture Wizard II, Just Scan (1:1 Pixel Matching): HDMI 1080p/1080i/720p, Component 1080p/1080i/720p, RF 1080p/1080i/720p, AV Mode (Picture & Sound): 3 Modes (Cinema/Game/Off), |
|
| AUDIO FEATURES |
| Speakers |
2 Way 5 Speakers |
| Stereo System |
Mono, Stereo, Dual |
| Sound Technology |
Dolby Digital Decoder, Clear Voice II with Virtual Surround |
| Sound Output RMS |
10W + 10W plus 10W (Subwoofer) |
| Additional Audio Features |
Sound Mode: 7 Modes (Standard/Music/Cinema/Sport/ Game/Vivid/User Setting), Sound Optimizer:3 Modes (Low/Medium/High), Mute (Normal/2 Level): Normal |
|
| CONNECTIVITY |
| Composite Video Input |
N.A |
| Component Video Input |
N.A |
| USB |
3 (Side) |
| HDMI |
Yes |
| Ethernet (RJ 45) |
N.A |
| PC Audio In (Mini Jack) |
N.A |
| Headphone Jack |
N.A |
| Digital Audio Output (Optical) |
N.A |
| Audio Out L-R (Mini Jack) |
N.A |
| RF Connection Input(s) |
N.A |
| Other Connectivity Features |
1 (Rear) RF In (Antenna/Cable), 1(Rear) AV In, 1 (Rear) Component Video In(Y, Pb, Pr) plus Audio, 1 (Rear) Digital Audio Out (Optical), 4 (Side) HDMI/HDCP Input, 1 (Rear) RGB In (D-Sub 15 Pin) � PC, 1 (Rear) PC Audio Input, 1 (Rear) LAN |
|
| FEATURES |
| Additional |
3D Type (SG/FPR): FPR (Passive), 3D Format Auto Correction, 3D to 2D, 2D to 3D, 3D Depth Control (3D & 2D to 3D):20 Levels, 3D Viewpoint Control (3D & 2D to 3D):20 Levels, 3D Image Correction, 3D Sound Zooming, Dual Play Capable: Yes (AG-F310DP glasses required and sold separately), Home Dashboard 2.0, App Store, Premium Content Providers, Full Web Browser, Social Centre, Search & Recommendation,3D World (3D Content Streaming), Smart Phone Remote Support, Language: 4 (English/Spanish/French/Korean), Auto Tuning/Programming, Channel Add/Delete, Favourite Channel Programming, Auto/Manual Clock, On/Off Timer, Sleep Timer, Auto Off/Auto Sleep, Built-in Wi-Fi Ready, MHL, 2nd TV Ready, WiFi Direct, Media Link, DLNA (Movie/Photo/Music), Windows 7 Certified, Intel Wireless Display (WiDi), SIMPLINK (HDMI CEC) |
|
| DESIGN & DIMENSIONS |
| Swivel & Tilt |
10/10 |
| Weight with Stand |
24.4 kg |
| W x H x D (Without Stand) |
55.3 x 30.4 x 4.5 |
| Weight without Stand |
20.5 kg |
| W x H x D (With Stand) |
48.1 x 30.8 x 13.1 |
|
| POWER |
| Power Supply |
AC 100-240 V, 50/60 Hz |
| Power Consumption |
0.3W (Standby) |
|
|
|
